Thiết bị chống sét, ASP surge protector AM-48DC (Single Mode) AM-48DC/2(2p)

  • Đăng ngày 03-08-2022 03:30:36 PM - 604 Lượt xem
  • Mã sản phẩm: S004167

  • Tình trạng sản phẩm:


    The AM-48DC modular power surge protector is designed according to IEC and GB standards. The DC power surge protector has a large surge discharge capacity, and the maximum discharge current is 20kA (8 20μs), which is suitable for the final protection of the DC power supply system.

    • 24-48VDC power supply select AM-48DC
    • The maximum discharge current of a single module is 20kA (8/20μs)
    • Failure detection indication
    • Remote signaling alarm interface (AM-**DC-S) S suffix
    • Standard Modular 35mm Rail Mount
    • Pluggable Replacement Modules
    • Built-in instantaneous overcurrent disconnect device
    • Built-in thermal circuit breaker

    Product performance parameters:
    model AM-48DC
    SPD port one port
    SPD category Pressure limiting type
    Power Systems DC power supply system
    Rated voltage Un 48VDC
    Maximum continuous operating voltage Uc 65VDC
    Nominal discharge current In(8/20μs) 10kA
    Maximum discharge current Imax(8/20μs) 20kA
    Protection level UP(8/20μs) <500V
    It is recommended to connect an overcurrent protection device in series 16A/6kA
    Response time ≤25ns
    size 1mods,DIN43880
    Failure indication Green: Normal Red: Failed
    Installation lead cross-sectional area 6-25mm 2
    Installation method 35mm standard rail (EN50022/DIN46277-3)
    Working temperature -40/70℃
    Shell material Thermoplastic material according to UL94 V-0
    Shell protection class IP20
    Certification CE RoHS
    Remote signaling alarm Normally open/normally closed contact terminal (optional)
    Cross-sectional area of ​​remote signaling terminal Up to 1.5mm2 single-strand wire/cord
    *Product parameters are subject to the actual product manual.
    The scope of products:
    • DC distribution panel
    • DC powered equipment
    • DC distribution box
    • Electronic information system cabinet (such as the DC line of the fire engine room
