Thiết bị chống sét, ASP surge protector ASP FLD1-15/100/4P ASP FLD1-25/140/4P ASP FLD1-50/180/4P ASP FLD1-15/100 (single piece) ASP FLD1-15/100/3+NPE ASP FLD1-25/140/3+NP

.

      Leixun FLD1-15/100 voltage switch type series first-level modular power surge arrester is a lightning protection product designed and applied to the power supply system according to the standard of IEC power surge arrester and GB standard. The product is a standard 35mm guide rail. installation method.
FLD voltage switch type series modular power supply lightning arrester has high lightning current discharge capability. The maximum impulse current of a single module can reach 50kA, which can prevent various surges including direct lightning strike, and is used in areas with high lightning risk. The power supply level lightning protection of the equipment system can be combined for single-phase/three-phase power supply lines.

ASP FLD1-50/180 gap type lightning arrester (single module), inrush current 50KA (10/350), design institute special model
ASP FLD1-25/140 gap type lightning arrester (single module), inrush current 25KA (10 /350), the design institute's special model
ASP FLD1-15/100 gap lightning arrester (single module), the inrush current is 15KA (10/350), the design institute's special model
ASP FLD100-NPE gap lightning arrester (single module) , N-PE module, special model for design institute
